Testing and Qualification

Fäth Group – Your partner for first-class testing and equipment qualification in high-demanding industrial sectors.

OVERVIEW
Equipment
EQUIPMENT FEATURES

Testing, Qualification and Commissioning of Ultrapure Media Plants

Fäth Group is a leading provider of testing and qualification services in the ultrapure media, semiconductor, photovoltaic and pharmaceutical industries.

Certified Staff

Our LT2 and VT2 certified staff will find, together with you, an individual answer to all questions, from qualification to commissioning of your equipment and process media.

Quality Assurance

With the latest technology, we set the standards in Quality Assurance. Our testing instruments are always up-to-date and calibrated, in function with short cycle times and with the highest measurement accuracy, ensuring the purity, impermeability and pressure resistance of ultra-pure gas, ultra-pure water and ultra-pure chemical systems.

High Compatible Equipment

The mobilized handling and the highly compatible technical equipment, position Fäth Group as the flexible partner for companies with the highest demands.

Our Renowned Laboratory Partners

Our partnerships with reputable laboratories expand our range of services and these enable us to offer differentiated and verified results.

Particle Measurement in High Purity Gases, Water and Chemicals

Our particle measuring instruments meet the most stringent requirements for testing gases, chemicals and ultrapure water. They are ideal instruments for the qualification of supply systems and also suitable for the qualification of cleanrooms. Our ultrapure water and chemical gauges are able to detect particles as small as 50 nm, while our gas meters can detect particles as small as 0.1 µm.

Residual Oxygen and Residual Moisture Measurement

The smallest residual amounts of oxygen (O2) and moisture can lead to serious production errors and downtimes. Our testing technology is characterized by high precision in electrochemical analysis. In gas supply systems where impurities can vary from the ppm to ppb range, we achieve sensitivities of < 1 ppb.

TOC and Conductivity Measurement

Our portable analyzers measure ppt levels of organic contaminants, using state-of-the-art UV oxidation and conductivity measurement technologies. We work with the lowest possible detection threshold for TOC measurements in distribution and process loops, with detection limits down to < 20 ppt.

Pressure Measurement

Fäth Group uses the latest pressure measurement technology to record positive or negative pressures and differential pressures – for liquid and gaseous media. Due to a wide variety of hook-ups, the devices prove to have a high level of system compatibility. Thus we can also take special user requirements into account. We measure in ranges from -1 to 600 bar (higher pressures on request). Our devices are equipped with data loggers for the analysis of test results.

Helium Leak Detection

Our helium testers quickly and reliably detect even the smallest leakages. Thanks to dry-running pumps, an absolutely oil-free leak detection is guaranteed. Instruments equipped with a remote control and sniffer probe are highly flexible and – thanks to pre-pumping – can also be used for large objects on site.

Residual Oil Measurement in Compressed Air

Residual oil measurements in compressed air systems can be performed from 0 to 2.5 mg/m³.

Video Endoscopy

By means of endoscopy, image and video recordings are possible from DN15 and special lengths up to 8m.

Test	Measuring device	Measuring range
Helium leak test	Pfeiffer Vacuum HLT570	< 1x 10-10 mbar*l/s
Pressure test	WIKA Hand Held	– 1 to 300 bar
Particle measurement in gas	PMS Lasair II aero trak 9110	0.1 – 5 μm
Particle measurement in ultrapure water and chemistry	HSLIS-M50 HSLIS-M65 lighthouse nanocount 50	0.05 – 0.2μm 0.065 – 0.2μm 0.05 – 0.2μm/ Zero count rate < 20 P/L
Moisture measurement in gas	Tiger Optics Halo+	1 ppb – 20 ppm
Air-oxygen measurement	GOX 100	0 -100 %
Residual oxygen measurement in gas	Servomex Nano Trace DF550	1 ppb – 10 ppm
Exhaust air volume measurement	Testo 435	Flow velocity up to 40m/s
Illuminance measurement	Testo 540	0 – 99999 lux
Sound level measurement	Testo 815	32 – 130 db
Residual oil measurement in compressed air systems	Metpoint OCV compact	0 – 2.5 mg/m³
TOC measurement in ultrapure water	Anatel A1000 XP Mettler Toledo 450TOC	0.02 – 1999 ppb 0.05 – 1000 ppb
Conductivity measurement in ultrapure water	Anatel A1000 XP Mettler Toledo 450TOC	15.0 – 18.2 Mohm/cm @25°C
Ferrite content measurement in austenitic and duplex steels	Fischer Feritscope FMP30	Fischer Feritscope FMP30
Analysis of anions, cations and bacterial count in ultrapure water and chemistry	Sampling by trained specialists	Analysis in external laboratory
